Product Description
![Custom Size Solar Panel Set for Home 440 445 450 455 500 W Wp Watt](https://img3.grofrom.com/soloryfsgroup/82528957c817cb13a0979364bda2442f.webp)
![Custom Size Solar Panel Set for Home 440 445 450 455 500 W Wp Watt](https://img3.grofrom.com/soloryfsgroup/32e608008b2465e3b8b71602efd9f04d.webp)
![Custom Size Solar Panel Set for Home 440 445 450 455 500 W Wp Watt](https://img3.grofrom.com/soloryfsgroup/82528957c817cb13a0979364bda2442f.webp)
![Custom Size Solar Panel Set for Home 440 445 450 455 500 W Wp Watt](https://img3.grofrom.com/soloryfsgroup/32e608008b2465e3b8b71602efd9f04d.webp)
ELECTRICAL DATA(STC)
Module | SPxxxM6-96 xxx = Peak Power Watts | ||||||
Peak Power Watts(Pmax/W) | 440 | 450 | 460 | 470 | 480 | 490 | 500 |
Power Output Tolerance(W) | 0~+5W | ||||||
Maximum Power Voltage(Vmp/V) | 47.78 | 47.87 | 48.01 | 48.25 | 48.35 | 48.45 | 48.63 |
Maximum Power Current(Imp/A) | 9.21 | 9.40 | 9.59 | 9.74 | 9.93 | 10.12 | 10.28 |
Open Circuit Voltage(Voc/V) | 58.50 | 58.57 | 58.75 | 58.82 | 58.89 | 58.93 | 58.95 |
Short Circuit Current(Isc/A) | 9.40 | 9.73 | 9.78 | 9.90 | 10.04 | 10.67 | 10.87 |
Module EffIciency(%) | 17.17 | 17.56 | 17.95 | 18.34 | 18.34 | 19.12 | 19.51 |
STC:Irradiance 1000W/m2,Cell Temperature 25°C,Air Mass AM1.5.
*Measuring tolerance: ±3%.
Grade A Material
Our Factory
Strict QC System
Professional Packing
Project Cases
