Model | YS320P-72 | YS330P-72 | YS340P-72 | YS350P-72 | YS360P-72 | YS370P-72 | YS380M-72 |
Rated Maximum Power at STC | 320W | 330W | 340W | 350W | 360W | 370W | 380W |
Maximum Power Voltage (Vmp) | 36.2V | 38.3V | 38.7V | 39.1V | 39.5V | 39.9V | 40.3V |
Maximum Power Current (Imp) | 8.29A | 8.62A | 8.79A | 8.94A | 9.12A | 9.27A | 9.43A |
Open Circuit Voltage ( Voc) | 45.2V | 46.7V | 47.1V | 47.5V | 48.0V | 48.4V | 48.8V |
Short Circuit Current (Isc) | 8.77A | 9.10A | 9.24A | 9.38A | 9.51A | 9.64A | 9.77A |
Module Efficiency | 15.44% | 16.91% | 17.42% | 17.94% | 18.45% | 18.97% | 19.59% |
Power Tolerance | 0~+3% | 0~+3% | 0~+3% | 0~+3% | 0~+3% | 0~+3% | 0~+3% |
STC: Irradiance 1000W/m², Module Temperature 25°c, Air Mass 1.5 | |||||||
Mechanical Parameters | |||||||
Cell Type | Poly-crystalline 156x156mm (6inch) | ||||||
No. of Cells | 72 (6x12) | ||||||
Dimension | 1956x990x40/45/50mm | ||||||
Glass | 3.2mm, High Transmission, Low Iron, Tempered Glass | ||||||
Junction Box | IP65&IP67 Rated | ||||||
Output Cable | Section Size: 4mm² , Length: 900mm | ||||||
Frame | Anodized Aluminum Alloy | ||||||
No. of Bypass Diodes | 3&6 | ||||||
Connector | MC4 Compatible | ||||||
Working Conditions | |||||||
Maximum System Voltage | DC 1000V(IEC) / 1500V(IEC) / 600V(UL) | ||||||
Operating Temperature | -40°c~+85°c | ||||||
Maximum Series Fuse | 15A | ||||||
NOCT | 45±2°c | ||||||
Application Class | Class A | ||||||
Temperature Coefficient | |||||||
Temperature Coefficient of Pmax | -0.40%/°c | ||||||
Temperature Coefficient of Voc | -0.30%/°c | ||||||
Temperature Coefficient of Isc | +0.05%/°c |
***** Factory Introduction *****
♦ Founded in 1994 , 300MW solar panel production capacity ,solar panel power range 3watt to 510watt for both polycrystalline and monocrystalline solar panel
♦ 10 years total workmanship and materials warranty , 10 years for at least 90% and 25 years for 80% linear power output warranty
♦ 100% EL test before package and shipping
♦ Two factories , solar panel factory , battery factory
♦ Cooperated with world famous big companies like Jinko Solar , Suntech Solar , Canadian Solar , HUAWEI
♦ Products are exported to more than 150 countries
♦ Products are certified by TUV(Germany) , UL(America) ,CE
♦ Turn-key solar systems are offered , to save the time and money for the clients
♦ Rich experience in overseas construction of solar projects
